62 / 122
62
תעשיית מתכת וחשמל בע”מ
METAL & ELECTRICITY INDUSTRY LTD
62
-0.1
+0.2
0.2
-0.1
+0.2
A
A
300
300
300
300
300
300
SECTION A-A
DETAIL F
SCALE 1 : 2
Screw M8x20
Flat washer (x2)
Nut M8
Helical spring lock washer
Instruction for assembly between two cabinets
6
5
4
3
7
8
9
10
3
4
5
6
7
8
Holes:
Slots:
Finish:
Remove itch and sharp edges
before bending. Polish weldings
and remove ricochets before point Tolerances:
General: ±0.5
Between Holes Centers: ±0.2
Angles: ±0.5°
Qty:
Nam
Weight:
Checked:
Drawn:
Designed:
The information contained in this
drawing is the sole property of
Tamhash. Any reproduction in
part or as a whole without the
written permission of Tamhash
is prohibited.
Approved:
Unless otherwise specifed:
Dimensions are in millimeters
Proprietary and Confidential
Material:
מינימום בכל צד
5 *
בורג
מקדימה וגם מאחורה
הוראות חיבור בין תאים
