Ui
מרחק זחילה לפי מתח הבדדה
Minimum creepage distance mm
Rated insulation
voltage Ui
Pollution degree
3
2
1
Material group ͨ
Material group ͨ
Material group ͨ
IIIb
IIIa
II
I
IIIa and IIIb
II
I
All material groups
Vᵇ
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
32
1.8
1.8
1.6
1.5
1.5
1.5
1.5
1.5
40
1.9
1.9
1.7
1.5
1.5
1.5
1.5
1.5
50
2
2
1.8
1.6
1.5
1.5
1.5
1.5
63
2.1
2.1
1.9
1.7
1.5
1.5
1.5
1.5
80
2.2
2.2
2
1.8
1.5
1.5
1.5
1.5
100
2.4
2.4
2.1
1.9
1.5
1.5
1.5
1.5
125
2.5
2.5
2.2
2
1.6
1.5
1.5
1.5
160
3.2
3.2
2.8
2.5
2
1.5
1.5
1.5
200
4
4
3.6
3.2
2.5
1.8
1.5
1.5
250
5
5
4.5
4
3.2
2.2
1.6
1.5
320
6.3
6.3
5.6
5
4
2.8
2
1.5
400
8
8
7.1
6.3
5
3.6
2.5
1.5
500
10
10
9
8
6.3
4.5
3.2
1.8
630
ª
12.5
11
10
8
5.6
4
2.4
800
16
14
12.5
10
7.1
5
3.2
1000
20
18
16
12.5
9
6.3
4.2
1250
25
22
20
16
11
8
5.6
1600
